Product information
The Datavideo MS-3200 is a mobile video production studio from Datavideo, supplied in India by Universal AV Solutions. MS-3200 HD 12-Channel Mobile Video Studio. All-in-One Video Production Studio in Rugged Flyaway Case.
Key features
- All-in-One Video Production Studio in Rugged Flyaway Case
- Built-in switcher, intercom, recorder, scope view monitor, and power supply
- 12-input Full HD production switcher (SE-3200)
- 17.3" Full HD pull-out monitor
- Intercom and talkback, PoE to 8 belt packs
- UHD 4K recording in 10-bit 4:2:2 ProRes (HDR-90)
- H.264 streaming and recording simultaneously (NVS-35)
- Several optional accessories
- Compatible with dvCloud
Technical specifications
- Model Number: MS-3200
- Digital Video Switcher: SE-3200
- 17.3" Rack Mount LCD: TLM-170VM x1
- Recorder: HDR-90 x1
- Intercom/Tally System: ITC-300 w/4 Belt Pack
- SDI Vector Scope: Built-in TLM-170VM
- Audio Mixer: AD-200
- Power Distributor (8-way): PD-2A
- Camera Power Distributor: PD-6 (optional)
- H.264 Video Streaming Server: NVS-35
- Rack System Integration: 8RU Flight Case
- Weight: 65 kg
- Operating Temp. Range: 0~40 °C
What's in the box (per official Datavideo page)
- 1 x MS-3200 product
- 4 x ITC-300SL Belt Pack
- 4 x Tally LED Indicator
- 4 x Headset with microphone
- 1 x Goose neck MIC
- 4 x Ethernet Cable
- 4 x RJ-45 Protective Shield Set
- 4 x GPI Cable
- 1 x AC Power Cord
- 1 x Y type USB cable
- 5 x 120mm cable tie
- 10 x 200mm cable tie
- 1 x Y type 2 pin MOLEX cable
- 2 x 2.5" HDD enclosure
Specifications are taken from the official Datavideo product page. Contact Universal AV Solutions for configuration, compatibility and project advice.
