Product information
The Datavideo SE-4000 is a video switcher from Datavideo, supplied in India by Universal AV Solutions. SE-4000 4K 8-Channel Digital Video Switcher. UHD 4K@50/60P across 8 channels.
Key features
- UHD 4K@50/60P across 8 channels
- Also operates as 12-channel UHD 4K@29/30P switcher
- 12G-SDI and HDMI 2.0 inputs
- 5-inch color touchscreen
- AUX, XPT, four color keyers, PIP, DSK
- Built-in input scaler and HD/4K conversion
- One-Button-One-Function control
- Two PIP windows with 3D borders
- 64 WIPE transition effects
- 250 still image stores
- 4 chromakeyers with Key Tie
- Up to 125 user memory presets
Technical specifications
- Model Number: SE-4000
- Video Standard: 4K & HD
- Video Format Input: 3840x2160p: 60/59.94/50/30/29.97/25; 1080p: 60/59.94/50/30/29.97/25; 1080i: 60/59.94/50
- Video Format Output: 3840x2160p: 60/59.94/50/30/29.97/25; 1080p: 60/59.94/50/30/29.97/25; 1080i: 60/59.94/50
- Video Processing: SDI: 4:2:2 10-bit; HDMI: YUV 4:2:2 10-bit, RGB: 4:4:4 8/10-bit
- Input Routable / Crosspoint: YES
- Video Input: Total 8 live inputs (select 8 from 12); 8 x 12G-SDI; 4 x HDMI
- Computer Graphic Interface: 4 via HDMI
- Video Output: 4 x 12G-SDI; 3 x HDMI; All assignable: Multiview, PGM, PVW, PGM+DSK, Clean PGM, Clean PVW, Input 1-12
- Down-converted Output: Yes
- Built-in Multi-view Monitoring Out: HDMI & SDI assignable
- Analogue Audio Input: 4 x Analogue XLR
- Analogue Audio Output: 2 x Analogue XLR
- Digital Embedded Audio Support: Input 4 channels, Output 4 channels
- Audio Delay Calibration: Up to 16 fields or 8 frames per channel
- A+V Switching: Yes
- Chromakey: 4
- Title Creator: Yes (Coming soon by firmware update)
- USK: 4x Keyer support Chromakey/ Linear/ Luma Key
- DSK: 2x DSK support Lumakey & Linear key (Key / Fill)
- Picture in Picture: 2
- Logo Insertion: 2
- Still Store: 250
- Effects: FTB, Cut, 32 Wipe with border
- Transition Preview: Full transitions preview
What's in the box (per official Datavideo page)
- 1 x SE-4000 Main Unit
- 1 x SE-4000 Control Board
- 2 x AD Switch DC 12V
- 1 x AC Cord
- 1 x Ethernet Cable
- 12 x Screw
- 2 x 2U Ear Rack
Specifications are taken from the official Datavideo product page. Contact Universal AV Solutions for configuration, compatibility and project advice.
