Product information
The Datavideo HBT-50 is a hdbaset receiver from Datavideo, supplied in India by Universal AV Solutions. HBT-50 - 4 channel HDBaseT Receiver. Powers and controls up to 4 devices up to 100 m.
Key features
- Powers and controls up to 4 devices up to 100 m
- Simultaneous HDMI, SDI, RS-422 and IP control outputs
- PoE power for PTZ cameras
- Single Ethernet cable transmission to and from the camera
- Remote control of camera parameters (iris, presets)
- SDI output to switcher
- SDI and HDMI up to 1080p60
- Simultaneous HDMI and SDI outputs
- RS-422 or DVIP camera control
Technical specifications
- Model Number: HBT-50
- Video/Audio Input: HDBaseT x 4 (with PoE and IEEE 802.3at); Cable Type: Cat6A shielded
- Video/Audio Output: HDMI x 4 (up to 1080p50/59.94/60); SDI x 4 (up to 1080p50/59.94/60)
- Supported Video Format: 1080p: 60/59.94/50/30/29.97/25/24/23.98; 1080i: 60/59.94/50, 720p: 60/59.94/50
- DVIP: RJ-45 x1 (input)
- RS-422/ RS-232: RJ-45 x 4 (RS-232/RS-422)
- Power: AC In
- PoE Output: 65W per channel
- HDBaseT Distance: 1080p50/59.94/60 up to 100m by CAT.6 cables
- Dimension (LxWxH): 440 x 286 x 49mm
- Weight: 4.2 kg
- Operating Temp. Range: 0~40 °C
What's in the box (per official Datavideo page)
- 1 x HBT-50 main unit
- 1 x AC Cord
Specifications are taken from the official Datavideo product page. Contact Universal AV Solutions for configuration, compatibility and project advice.
